Section III: Web Browser Management
252
Setting the Switch’s VLAN Mode
This section contains the procedure for setting a stack’s VLAN mode. You
can configure a stack to support port-based and tagged VLANs or to
operate in the Basic VLAN mode. A stack can operate in only one VLAN
mode at a time.
Note
Refer to Chapter 10, Virtual LANs, for background information on
port-based and tagged VLANs and the Basic VLAN mode.
To set the stacks VLAN mode, perform the following procedure:
1. From the Home Page, select Configuration.
The Configuration window is displayed with the System menu
option selected by default.
2. If the System menu option is not selected, select it.
3. Select the General tab.
The General tab window is displayed in Figure 107.
Figure 107 Configuration - General Window
