Allied Telesis AT-S25 - Manual (Page 152)

Section II: Local and Telnet Mangement
152
Viewing
Multicast MAC
Addresses Only
To display only multicast MAC addresses, perform the following
procedure:
1. From the Main Menu, type 6 to select MAC Menu.
2. From the MAC Menu, type 3 to select Show all multicast MAC
addresses.
A window is displayed with all the multicast MAC addresses. An
example of the Show all multicast MAC addresses window is
shown in Figure 59.
Figure 59 Show all multicast MAC addresses Window
Table 12 lists the parameters used in the Show all multicast MAC
addresses window.
Table 12 Show all multicast MAC addresses Parameters
PARAMETER DESCRIPTION
MAC Address The multicast MAC address.
VlanID The VID of the VLAN where the port is an untagged
member.
Module The selected module.
Port List The port list on the switch where the multicast MAC
address was learned.
