AT-S25 Management Software User’s Guide
45
Configuring an IP Address and Switch Name
The procedure in this section explains how to manually assign an IP
address, subnet mask, and gateway address to an AT-8300 Series stack
from a local or Telnet management interface. (If you want the stack to
obtain its IP configuration from a DHCP or BOOTP server on your
network, go to the procedure Activating the BOOTP and DHCP
Services on page 46.)
This procedure also explains how to assign a name to a stack, along with
other optional information, such as the name of the administrator
responsible for maintaining the unit and any comments; for example,
the location of the stack.
To manually assign an IP address and other information, perform the
following procedure:
1. From the Main Menu, type 4 to select Administration Menu.
The Administration Menu as shown in Figure 10 on page 43 is
displayed.
2. Make sure that the BootP/DHCP parameter is Disabled.
3. Enter or modify the parameters in the window as desired.
For information on these parameters, refer to Table 1 on page 43.
Changes to the parameters take effect immediately on the switch.
4. After you have set the parameters, type S to select Save Configuration
changes.
Note
A change to a parameter in this menu, including the IP address,
subnet mask, and gateway address, is immediately activated on a
stack.
