Section II: Local and Telnet Mangement
124
Table 10 lists the ports assignments for the Sales and Production VLANs:
Each VLAN is briefly summarized below:
❑ Sales VLAN
— This VLAN has been assigned a VID of 2 and the
ports, correspondingly, have been automatically assigned a PVID
also of 2. This VLAN spans the AT-8300 Series stack and the AT-
8024 Switch. Ports 1 to 6 on the Master AT-8324 Switch and ports
1 to 4 on the Slave switch are connected to workstations and a
server. Port 7 on the Master switch is connected to the router,
which gives the Sales VLAN access to the Production VLAN and
also to the WAN. Port 8 on the Slave switch is functioning as a
direct link to the second part of the Sales VLAN, located on the AT-
8024 Switch.
❑ Production VLAN
— This VLAN has been assigned a VID of 3 and
the ports a PVID of 3. Ports 19 to 24 on the Master AT-8324 Switch
and ports 21, 23, and 24 on the Slave switch are connected to
workstations. Port 17 on the Master switch is connected to a
router for interconnection to the Sales VLAN and the WAN, and
port 20 on the Slave switch is connected to the AT-8024 Switch to
interconnect the two parts of the Production VLAN.
Table 10 Port Assignments of the Port-based VLAN Example
Switch
Sales VLAN
(VID 2) Production VLAN
(VID 3)
AT-8324 Switch (Master) Ports 1 - 7 (PVID 2) Ports 17, 19 - 24
(PVID 3)
AT-8324 Switch (Slave) Ports 1 - 4, 8 (PVID 2) Ports 20, 21, 23, 24
(PVID 3)
AT-8024 Switch Ports 1 - 4, 7 (PVID 2) Ports 19, 21 -2 4
(PVID 3)
