Section II: Local and Telnet Mangement

Note

Do not connect the terminal to the RS-232 port on a slave switch. To
start a local management interface on a stack, you must connect the
terminal to the RS-232 port on the master switch.

2. Connect the other end of the cable to an RS-232 port on a terminal or

PC with a terminal emulator program.

3. Configure the terminal or terminal emulator program as follows:

❑ Baud rate: 9600 bps

❑ Data bits: 8

❑ Parity: None

❑ Stop bits: 1

❑ Flow control: None

Note

The port settings are for a DEC VT100 or ANSI terminal, or an
equivalent terminal emulator program.

When prompted for the user name and password, enter one of
the following options:

4. When prompted for a user name and password, do one of the

following:

❑ For Manager access, type manager as the user name. The default

password is “friend”.

❑ For Operator access, type operator as the user name. The default

password is “operator”.

Note

The user names and passwords are case sensitive.

The user names cannot be changed. For instructions on how to
change a password, refer to Configuring the Management
Passwords on page 51. For information on the two access levels,
refer to Management Access Levels on page 32.
