COMMAND DETAILS
87
Reference Commands
:REF:DISPlay ......................................................... 87
:REF:TIMebase:POSition ..................................... 87
:REF:TIMebase:SCALe ......................................... 88
:REF:OFFSet ......................................................... 88
:REF:SCALe ........................................................... 89
:REF:DISPlay
Description Sets or queries a reference waveform to be shown
on the display. A reference waveform must first be
saved before this command can be used.
Syntax :REF:DISPlay { OFF| ON| ? }
Parameter Reference waveform 1, 2
OFF Turns the selected reference
waveform off
ON Turns the selected reference
waveform on
Return parameter Returns the status of the selected reference
waveform. (OFF, ON)
Example :REF1:DISPlay ON
Turns on reference1 (REF 1) on the display.
:REF:TIMebase:POSition
Description Sets or returns the selected reference waveform
time base position.
Syntax :REF:TIMebase:POSition { | ?}
Related
commands :REF:DISPlay
Set
Query
Set
Query
