GDS-200 & GDS-300 Programming Manual
38
Math Commands
:MATH:DISP ................................................................ 38
:MATH:TYPe ................................................................ 38
:MATH:DUAL:SOURce ......................................... 39
:MATH:DUAL:OPERator ............................................. 39
:MATH:DUAL:POSition ............................................... 40
:MATH:DUAL:SCALe ................................................... 40
:MATH:FFT:SOURce ................................................... 40
:MATH:FFT:MAG ........................................................ 41
:MATH:FFT:WINDow .................................................. 41
:MATH:FFT:POSition .................................................. 41
:MATH:FFT:SCALe ...................................................... 42
:MATH:FFT:HORizontal:SCALe .................................. 42
:MATH:FFT:HORizontal:POSition .............................. 42
:MATH:DISP
Description Turns the math waveform on or off on the screen.
Syntax :MATH:DISP {OFF|ON|?}
Related
commands :MATH:TYPe
Parameter/
Return parameter OFF Math waveform is not displayed
ON Math waveform is displayed on screen
Example :MATH:DISP OFF
Turn the Math waveform off.
:MATH:TYPe
Description Queries or sets the Math type to FFT or to dual
channel math operations
Syntax :MATH:TYPe { DUAL | FFT | ? }
Set
Query
Set
Query
