GDS-200 & GDS-300 Programming Manual

48

Return parameter

Returns the cursor position.

Example

:CURSor:V2Position 1.1E-1
Sets the V2 cursor position to 110mV.

:CURSor:VDELta

Description

Returns the delta of V1 and V2.

Syntax

:CURSor:VDELta?

Return Parameter

Returns the difference between two
vertical cursors.

Example

:CURSor:VDELta?
4.00E+0
Returns the vertical delta as 4 volts.

:CURSor:XY:RECTangular:X:POSition

Description

Sets or queries the horizontal position in XY mode
for the X rectangular coordinates for cursor 1 or 2.

Syntax

:CURSor:XY:RECTangular:X:POSition {NRf|?}

Parameter

Cursor 1, 2

Horizontal position co-ordinates

Return parameter Returns the cursor position.

Example

:CURSor:XY:RECTangular:X:POSition1 4.0E-3
Sets the X-coordinate cursor 1 position to
40mV/mV.

:CURSor:XY:RECTangular:X:DELta

Description

Returns the delta value of cursor 1 and 2 on the X
coordinate.

Syntax

:CURSor:XY:RECTangular:X:DELta?

Query

Set

Query

Query
