COMMAND DETAILS

39

Related
Commands

:MATH:DISP

Parameter/
Return parameter

DUAL

Dual channel operations

FFT

FFT operations

Example

:MATH:TYPe DUAL

Sets the Math type to dual channel math operation.

:MATH:DUAL:SOURce

Description

Sets the dual math source for source 1 or 2.

Syntax

:MATH:DUAL:SOURce { CH1 | CH2 | REF1 | REF2
| ? }

Parameter

Source number 1 or 2

CH1~2

Channel 1 to 2

REF1~2

Reference waveforms 1 to 2

Return parameter Returns the source for the source 1 or 2.

Example

:MATH:DUAL:SOURce1 CH1
Sets source1 as channel 1.

:MATH:DUAL:OPERator

Description

Sets the math operator for dual math operations.

Syntax

:MATH:DUAL:OPERator {PLUS | MINUS | MUL | DIV
| ?}

Parameter

PLUS

+ operator

MINUS

- operator

MUL

operator

DIV

÷ operator

Return parameter Returns operator type.

Example

:MATH:DUAL:OPERator PLUS
Sets the math operator as plus (+).

Set

Query

Set

Query
