GDS-200 & GDS-300 Programming Manual
36
:CHANnel:PROBe:RATio
Description Sets or returns the probe attenuation factor.
Syntax :CHANnel:PROBe:RATio { | ?}
Related
Commands :CHANnel:PROBe:TYPe
Parameter Channel 1, 2
Probe attenuation factor.
Return parameter Returns the probe factor.
Example :CHANnel1:PROBe:RATio 1.00E+0
Sets the Channel 1 probe attenuation factor to 1x
:CHANnel:PROBe:TYPe
Description Sets or returns the probe type (voltage/current).
Syntax :CHANnel:PROBe:TYPe { VOLTage | CURRent | ?}
Related
Commands :CHANnel:PROBe:RATio
Parameter Channel 1, 2
VOLTage Voltage
CURRent Current
Return parameter Returns the probe type.
Example :CHANnel1:PROBe:TYPe VOLTage
Sets the Channel 1 probe type to voltage.
:CHANnel:SCALe
Description Sets or returns the vertical scale. The scale depends
on the probe attenuation factor.
Note the probe attenuation factor should be set
before the scale.
Set
Query
Set
Query
Set
Query
