GDS-200 & GDS-300 Programming Manual
24
*IDN?
Description Returns the manufacturer, model, serial number
and version number of the unit.
Syntax *IDN?
Example *IDN?
GW,GDS-310,PXXXXXX,VX.XX
*LRN?
Description Returns the oscilloscope settings as a data string.
Syntax *LRN?
Example
*LRN?
:DISPlay:WAVEform VECTOR;PERSistence Short;INTensity:
WAVEform 50;INTensity:GRATicule 50;GRATicule FULL;BRIGHTness
80;:ECO ON;:ECO:TIMe 1;:CHANnel CH1:DISPlay ON;BWLimit
OFF;COUPling DC;INVert OFF;POSition 3.600E+00;PROBe:RATio
1.000e+00;PROBe:TYPe VOLTAGE;SCALe 2.000E+00;EXPand
GROUND;:CHANnel CH2:DISPlay ON;BWLimit OFF;COUPling
DC;INVert OFF;POSition -4.000E+00;PROBe:RATio
1.000e+00;PROBe:TYPe VOLTAGE;SCALe 2.000E+00;EXPand
GROUND;:MATH:TYPe DUAL;DISP OFF;DUAL:SOURce1
CH1;SOURce2 CH2;OPERator PLUS;POSition 0.000E+00;
SCALe ;FFT:SOURce CH1;MAG DB;WINDow HANNING;POSition
0.000E+00;SCALe ?;:TIMebase:MODe MAIN;SCALe 5.000E-
04;POSition -1.150E-04;WINDow:SCALe 5.000E-
06;:MEASure:GATingSCREEN;SOURce1 CH1;SOURce2
CH2;:ACQuire:MODe SAMPE;AVERage 4;:CURSor:SOURce
CH2;MODeOFF;H1Position ;H2Position ;V1Position ;V2Position ;:
HARDcopy:MODe SAVE;SAVEFORMat PNG;ASSIGN
IMAGE;:TRIGger:FREQuency 2.000E+00;TYPe EDGE;SOURce
CH2;COUPle DC;NREJ OFF;REJect OFF;MODe AUTO;HOLDoff
1.000e-08;LEVel 4.000E-01;EDGe:SLOP RISE;PULSEWidth:POLarity
POSITIVE;VIDeo:TYPe NTSC;VIDeo:FIELd FIELD1;VIDeo:LINe
1;VIDeo:POLarity NEGATIVE;PULSe:WHEn
LESSTHAN;PULSe:TIME 0.000;ALTernate OFF;:REF1:DISPlay
OFF;OFFSet ;SCALe ;TIMebase:POSition ;SCALe ;:REF2:DISPlay
OFF;OFFSet -8.000E-01;SCALe 2.000E+00;TIMebase:POSition
0.000E+00;SCALe 5.000E-07;:ROTATELANDscape(1);
REPLAY:TOTalnum3000;:REPLAY:CURRent3000; :DMM:Mode:DCV;
:Value:0.000;:Max Value:0.000;:Min Value:-
0.003;:Hold:ON;:BRIEF:MODe ON;DATE OFF; VERTicalOFF;
Query
Query
