Installation, 2 installation 11 – Watlow CPC400 User Manual
Page 25
Doc.0600-2900-2000
Watlow Anafaze
11
2
Installation
This chapter describes how to install the CPC400 series
controller and its peripherals. Installation of the controller
involves the following procedures:
•
Determining the best location for the controller
•
Mounting the controller and TB50
•
Power connection
•
Input wiring
•
Communications wiring (EIA/TIA-232 or EIA/TIA-
485)
•
Output wiring
WARNING!
Risk of electric shock. Shut off power to your en-
tire process before you begin installation of the
controller.
WARNING!
The controller may fail in a 0 percent or 100 per-
cent power output state. To prevent death, per-
sonal injury, equipment damage or property
damage, install external safety shutdown devices
that operate independently from the process con-
trol equipment.
