Chapter 5: Menu and Parameter Reference CPC400 Series User’s Guide
100 Watlow Anafaze Doc. 0600-2900-2000
Power Up Alarm Delay
Specify how long to delay high, low and deviation alarms on
all loops during powerup. This feature does not delay failed
sensor alarms.
Values: 0 to 60 minutes
Default: 0
Modbus Address: 40409
Parameter Number: 24
LogicPro Driver: Database
LogicPro Address: 24.1
Power Up Loop Mode
Choose the power-up state of the control outputs.
Values: See Table 5.5. For serial communications and Log-
icPro, this is a bit-wise parameter stored as the first bit of
the system command word, so set or read only that bit.
Default: manual 0% (0)
Modbus Address: 49790, first bit
Parameter Number: 49
LogicPro Driver: Database
LogicPro Address: 49.1, first bit
WARNING! Do not set the controller to start from memory if it
might be unsafe for the control outputs to be on
upon power up.
Table 5.5 Power Up Loop Modes
Power Up With Logic
If you are using a logic program, choose whether it should
run automatically upon powerup of the controller.
Values: stopped (0) or running (1). Values in parentheses
are for serial communications and LogicPro.
Default: stopped (0)
Modbus Address: 45308
Parameter Number: 131
LogicPro Driver: Database
LogicPro Address: 131.1
Display
Value
Modbus or
LogicPro Value
Description
manual 0% 0
Upon powerup, all loops are set to manual mode at 0 per-
cent output.
from memory 1
Upon powerup, all loops are restored to the previous control
mode and output power level.
lPower up alarmr
delay b 0 min
lPower up loop r
modebmanual 0%
lPower up with r
logic bstopped
