Chapter 7: Specifications CPC400 Series User’s Guide
168 Watlow Anafaze Doc. 0600-2900-2000
Table 7.6 CPC400 Connections
TB50 Physical Specifications
Table 7.7 TB50 Physical Dimensions
Power Terminals (TB2) Captive screw cage clamp
Power Wire Gauge (TB2) 22 to 18 AWG (0.5 to 0.75 mm
2
)
Power Terminal Torque (TB2) 4.4 to 5.3 in.-lb. (0.5 to 0.6 Nm)
Sensor Terminals (TB1) Captive screw cage clamp
Sensor Wire Gauge (TB1)
Thermocouple: 20 AWG (0.5 mm 2 )
Process: 22 to 20 AWG (0.5 mm 2 )
Communications: 24 AWG (0.2 mm 2 )
Sensor Terminal Torque (TB1) 4.4 to 5.3 in.-lb. (0.5 to 0.6 Nm)
Output Terminals (TB18) Captive screw cage clamp
Output Wire Gauge (TB18)
Multiconductor cables: 24 AWG (0.2 mm 2 )
Single-wire: 22 to 18 AWG (0.5 to 0.75 mm 2 )
Output Terminal Torque (TB18) 4.4 to 5.3 in.-lb. (0.5 to 0.6 Nm)
SCSI Connector SCSI-2 female
Weight 0.32 lb. 0.15 kg
Length 4.1 inches 104 mm
Width 4.0 inches 102 mm
Height 1.5 inches 37 mm
