Chapter 1 System Design
1-5
(7)
(9)
(9)
(10)
(11)
(9)
(9)
(9)
(11)
Online Adapter
CA4-ADPONL-01
RS-422 Cable
(Prepared by user)
Multi-Link Cable
CA3-CBLMLT-01
RS-422 Cable
CA3-CBL422-01
Terminal Block
Conversion Adapter
CA3-ADPTRM-01
Mitsubishi PLC A, QnA,
FX Series' 2 Port Adapter II
GP070-MD11
2 Port Adapter Cable
CA3-MDCB11
Siemens COM Port
Conversion Adapter
CA3-ADPSEI-01
PROFIBUS Cable
(Prepared by user)
(10)
MPI Cable
CA3-MPI-PGN-PFE
CA3-MPI-PG1-PFE
RS-422 Cable
(Prepared by user)
Multi-Link Cable
CA3-CBLMLT-01
RS-422 Cable
CA3-CBL422-01
Terminal Block
Conversion Adapter
CA3-ADPTRM-01
Mitsubishi PLC A, QnA,
FX Series' 2 Port Adapter II
GP070-MD11
2 Port Adapter Cable
CA3-MDCB11
Host Controller
PLC etc.
(9)
MPI Cable
GP3000-MPI21-PFE
(10)
*Online adapter is
required for these
cases:1:1 Communication.
For use in 1:n, n:1,
n:m communication terminal
(1 unit can be used.)
