Panel cut dimensions – Proface AGP3500 - 10.4 DIO HMI" User Manual
Page 123
GP3000 Series Hardware Manual
4-58
Panel Cut Dimensions
AGP-35*0T
Unit: mm[in.]
AGP-3500L/AGP-3500S
Unit: mm[in.]
•
Please read “8.1 Installation” before designing the Panel Cut.
•
Please read “8.1 Installation” before designing the Panel Cut.
259
+1
-0
201
+1
-0
r
≤ 3 [0.12]
Panel thickness area
1.6[0.06] to 10.0[0.39]
[10.20 ]
+0.04
-0
[7
.9
1
]
+0.
0
4
-0
301.5
+1
-0
2
27.5
+1
-0
r
≤ 3 [0.12]
Panel thickness area
1.6[0.06] to 10.0[0.39]
[11.87 ]
+0.04
-0
[8.
9
6
]
+0
.0
4
-0
