Panel cut dimensions, Installation fasteners – Proface AGP3500 - 10.4 DIO HMI" User Manual
Page 107
GP3000 Series Hardware Manual
4-42
Panel Cut Dimensions
Unit: mm[in.]
Installation Fasteners
Unit: mm[in.]
•
Please read “8.1 Installation” before designing the Panel Cut.
204.5 +1
-0
1
59.5
+1
-0
r
≤ 3 [0.12]
Panel thickness area
1.6[0.06] to 10.0[0.39]
[6.28
]
+0
.0
4
-0
[8.05 ]
+0.04
-0
16.6[0.65]
11
[0
.4
3
]
16[0.63]
31[1.22]
M6
Φ
10[0.39]
