System configuration, 4 system configuration, Dc24v – IAI America SCON-C User Manual
Page 23
5
1.4 System
Configuration
Caution: The customer must provide a noise filter. A noise filter is always required at the minimum, even
when your system need not conform to the EC Directives. Also add clamp filters, etc., if necessary.
EMG switch
Regenerative
resistance unit
It may become
necessary depending
on the use condition.
Breaker
Note) Noise filter
MC1210 by
Densei-Lambda
Grounded
Teaching
pendant
Host control
system
Brake power
supply
PC
Absolute battery
Actuator
Absolute
battery
DC24V
