Extron Electronics MTPX Plus 6400 Series User Guide - Manual (Page 95)

Using the Matrix Switcher Control Software
Many items found in the Matrix Switchers Control Program are also accessible under
SIS control (see
Programming Guide ). The Matrix Switcher + Help Program provides
information on settings and on how to use the control program, itself.
NOTE: The first time you connect to the Configuration (USB) port, the Found New
Hardware Wizard appears (see figure 31) (see “ Activating a USB Port for the
First Time ,” below).
For other connections, proceed to “ Starting the program “ on the next page.
1
1
2
2
Figure 31. Found New Hardware Wizard
Activating a USB Port for the First Time
The first time you connect to the Configuration (USB) port, the Found New Hardware Wizard
appears (see figure 31). Activate the connected USB port for your device as follows:
NOTE: If you have not installed the latest Matrix Switchers Control Program (version 8.0
or newer), click Cancel and install the program. Reconnect the switcher to the
Configuration port.
1. Select the No, not this time radio button and click Next .
2. Select the Install the software automatically radio button and click Next .
Follow the on-screen instructions. The wizard assigns the driver necessary to access the
switcher to the connected Configuration (USB) port (this may take a few minutes).
3. Click Finish to exit the wizard.
4. Proceed to “ Starting the program “ on the next page or return to “ Programming
Guide .”
NOTE: You may need to repeat these steps if you subsequently connect the
switcher to a different USB port on the same computer.
MTPX Plus 6400 Series Matrix Switchers • Matrix Software 89
