Video output — local
Number/signal type ........................ 4 analog RGBHV, RGBS, RGsB, RsGsBs, component video (bi-level and tri-level
sync), S-video, composite video
Connectors .................................... 4 female 15-pin HD
Nominal level ................................. 1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Impedance ..................................... 75 ohms ±10%
Return loss ..................................... <-30 dB @ 5 MHz
DC offset ....................................... =40 mV with input at 0 offset
Video output — main (see receivers' input specifications)
Number/signal type ........................ 32, 48, or 64 proprietary analog signals
Connectors .................................... 32, 48, or 64 female RJ-45 connectors
Sync — local inputs and outputs only
Input type ...................................... RGBHV, RGBS, RGsB, RsGsBs
Output type ................................... See receiver specifications (on Web site).
Standards ....................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level ...................................... 2.5 V to 5.5 VDC
Output level ................................... See receiver specifications (on Web site).
Input impedance ............................ 611 ohms ±5%
Output impedance ......................... 75 ohms ±20 ohms
Max. output voltage ....................... ≤4 VDC with a 2k ohm load
Max. propagation delay .................. 60 ns
Max. rise/fall time ........................... 4 ns
Polarity ........................................... Positive or negative (selectable)
Audio
Routing
MTPX Plus 4848 ...................... 48 x 48 mono matrix, 8 x 8 local
MTPX Plus 4864 ...................... 48 x 64 mono matrix, 8 x 8 local
MTPX Plus 6432 ...................... 64 x 32 mono matrix, 8 x 8 local
MTPX Plus 6448 ...................... 64 x 48 mono matrix, 8 x 8 local
MTPX Plus 6464 ...................... 64 x 64 mono matrix, 8 x 8 local
Gain ............................................... Unity: 0 dB ±2 dB with a 600 ohm load, single ended
Frequency response ........................ 20 Hz to 20 kHz, ±1 dB
THD + Noise ................................... =0.05% @ 1 kHz at nominal level
S/N ................................................. >90 dB at 20 Hz to 20 kHz
CMRR ............................................ >80 dB @ 20 Hz to 20 kHz
Audio input — local
Number/signal type ........................ 8 stereo, balanced/unbalanced
Connectors .................................... (8) 3.5 mm captive screw connectors, 5 pole
Impedance ..................................... >10k ohms balanced/unbalanced, DC coupled
Nominal level ................................. +4 dBu (1.23 Vrms)
Maximum level ............................... >+18 dBu, (balanced/unbalanced) at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio input — main (see transmitters' output specifications)
Number/signal type ........................ 48 or 64 proprietary analog signals
Connectors .................................... 48 or 64 female RJ-45 connectors
MTPX Plus 6400 Series Matrix Switchers • Reference Information 155
