Reset Mode Comparison/Summary
Mode Activation
Result
Purpose/Notes
1
Hold down the recessed Reset button
while applying power to the switcher.
NOTE: After a mode 1 reset is
performed, update the
switcher firmware to the latest
version. Do not operate the
switcher firmware version that
results from the mode 1 reset.
If you want to use the factory
default firmware, you must
upload that version again
(see “
for details on uploading
firmware).
The switcher reverts to the factory default firmware. Event
scripting will not start if the switcher is powered on in
this mode. All user settings and files, such as the current
configuration and IP settings, are maintained.
NOTE: If you do not want to update firmware, or you
performed a mode 1 reset by mistake, cycle
power to the switcher to return to the firmware
version that was running before the mode 1
reset. Use the 0Q SIS command to confirm
that the factory default firmware is no longer
running (look for the asterisk [*] following the
version number.
Use mode 1 to revert
to the factory default
firmware version if
incompatibility issues
arise with user-loaded
firmware.
3
Hold down the Reset button for
about 3 seconds, until the Reset LED
flashes several times, then press Reset
momentarily (<1 second) within 1
second.
Mode 3 turns events on or off. During resetting, the Reset
LED flashes when events are starting and stopping.
Mode 3 is useful for
troubleshooting.
4
Hold down the Reset button for
about 6 seconds, until the Reset LED
flashes several times at 3 seconds
and again at 6 seconds. Then press
Reset momentarily (<1 second) within
1 second.
Mode 4:
•
Enables ARP capability.
•
Sets the IP address to the factory default.
•
Sets the subnet address to the factory default.
•
Sets the gateway address to the factory default.
•
Sets port mapping to the factory default.
•
Turns DHCP off.
•
Turn events off.
The Reset LED flashes three times in quick succession
during the reset.
Mode 4 enables you
to set IP address
information using ARP
and the MAC address.
5
Hold down the Reset button for about
9 seconds, until the Reset LED flashes
several times at 3 seconds, again at
6 seconds, and then again at 9 seconds.
Then press Reset momentarily
(<1 second) within 1 second.
Mode 5 performs a complete reset to factory defaults
(with the exception of the firmware):
•
Does everything mode 4 does.
•
Resets most settings including:
clears all ties and presets
clears all audio or RS-232 output mutes
clears all I/O grouping
clears all input level and peaking
clears all skew adjustments
clears all output pre-peaking
disables all RS-232 output inserts
sets all audio/RS-232 wire pairs to audio
clears all audio settings
•
Resets all IP options.
•
Removes/clears all files for the switcher.
The reset LED flashes three times in quick succession
during the reset.
Mode 5 is useful if
you want to start over
with configuration
and uploading or
to replace events.
This is the same as
the
SIS
command.
