Command/Response Table for SIS Commands
Symbol Definitions
]
= CR/LF (carriage return/line feed) (hex 0D 0A)
}
= Carriage return (no line feed, hex 0D)
|
= Pipe (can be used interchangeably with the
}
character)
•
= Space character
E
= Escape key (hex 1B)
X!
= Input number (for tie)
00 – (maximum number of inputs for your matrix size) (00 = untied)
X@
= Output number
01 – (maximum number of outputs for your matrix size)
X#
= TP input number
01 – (maximum number of TP inputs for your matrix size)
X$
= Audio / RS-232 wire pair input type
0 = audio
1 = RS-232
X%
= RS-232 output insertion port number
01 – 16
X^
= RS-232 output insert status
0 = disabled
1 = RS-232 enabled
2 = UART enabled
X&
= Input level and peaking range
000 – 255
X*
= Threshold
0 = outside of threshold
1 = within threshold
X(
= Skew adjustment range
00 – 31 (each step = 2 ns)
X1)
= Video plane
0 = red
1 = green
2 = blue
X1!
= Input number
01 – (maximum number of inputs for your matrix size)
X1@
= DDC value (EDID)
00 = Automatic
18 = 1366 x 768 @ 60 Hz
01 = Output 1
19 = 1400 x 1050 @ 50 Hz
02 = Output 2
20 = 1400 x 1050 @ 60 Hz
03 = 800 x 600 @ 50 Hz
21 = 1440 x 900 @ 50 Hz
04 = 800 x 600 @ 60 Hz
22 = 1440 x 900 @ 60 Hz
05 = 1024 x 768 @ 50 Hz
23 = 1600 x 1200 @ 50 Hz
06 = 1024 x 768 @ 60 Hz
24 = 1600 x 1200 @ 60 Hz
07 = 1280 x 720 @ 50 Hz
25 = 1680 x 1050 @ 50 Hz
08 = 1280 x 720 @ 60 Hz
26 = 1680 x 1050 @ 60 Hz
09 = 1280 x 768 @ 50 Hz
27 = 1920 x 1080 @ 50 Hz
10 = 1280 x 768 @ 60 Hz
28 = 1920 x 1080 @ 60 Hz
11 = 1280 x 800 @ 50 Hz
29 = 1920 x 1200 @ 50 Hz
12 = 1280 x 800 @ 60 Hz
30 = 1920 x 1200 @ 60 Hz
13 = 1280 x 1024 @ 50 Hz
31 = User defined
14 = 1280 x 1024 @ 60 Hz
32 = User defined
15 = 1360 x 768 @ 50 Hz
33 = User defined
16 = 1360 x 768 @ 60 Hz
34 = User defined
17 = 1366 x 768 @ 50 Hz
X1#
= Mute, pre-peaking, Lock mode
0 = off / Mode 0 / not OK or not installed
1 = on / Mode 1 / OK
2 = Mode 2
X1$
= Local video output number
01 – 04
X1%
= Local output sync polarity
0 = H– / V– (default)
1 = H+ / V–
2 = H – / V+
3 = H+ / V+
4 = No sync processing (composite, S-video, YUV)
X1^
= TP output number
01 – (maximum number of TP outputs for your model)
X1&
= Local audio output number
01 – 08
X1*
= Volume adjustment range
00 – 64 (1 dB per step) (default = 64 [0 dB])
(
X1(
= Audio gain
00 – 24 (1 dB per step)
X2)
= Numeric dB value
–18 to + 24 (45 steps of gain or attenuation (default = 0 dB)
X2!
= Audio attenuation
01 – 18 (1 dB per step)
