X2@
= Global or room preset number
00 – 64 (global) (00 = current default) or 01 – 10
NOTE: A
room preset is a stored configuration with all of the outputs assigned to a single room. When a room preset is recalled from
memory, it becomes the current configuration.
X2#
= Name
12 characters maximum for input, output, and global preset names
11 characters maximum for room preset names
Upper- and lower-case alphanumeric characters and
_ / and spaces are valid.
NOTE: The following characters are invalid or not recommended in the name: {space} ~ , @ = ‘ [ ] { } < > ’ “ ” ; : | \ and ?.
X2$
= Room number (for room presets)
01 – 10
NOTE: A room is a subset of operator selected outputs that relate to each other. The MTPX matrix switcher supports up to 10 rooms, each
of which can consist of from 1 to 10 outputs.
X2%
= Group number (for I/O grouping)
1 – 4 or 0 = no group
X2^
= Audio or RS-232 mute
0 = no mutes
2 = audio or RS-232 mute
X2&
= Local input select DIP switch position
0 = RJ-45 position
1 = local input position
X2*
= Number of inputs
48 or 64
X2(
= Number of outputs
32, 48, or 64
X3)
= Part number
X3!
= Firmware version number to second decimal place (n.nn)
X3@
= Verbose firmware version-description-upload date and time See the “
Query firmware version (verbose)
X3#
= Voltage
Voltage, polarity (positive or negative) and magnitude
X3$
= Internal temperature
Degrees Fahrenheit
X3%
= Fan speed (in RPM)
X3^
= Power supply status
0 = Out of tolerance or failed
1 = Ok
