d
Preset button — The Preset button has two primary functions (
❏
) and three secondary
functions (
•
):
❏
Activates
Save Preset mode to save a configuration as a preset and Recall
Preset mode to activate a previously-defined preset.
❏
Blinks when Save Preset mode is active and lights steadily when Recall
Preset mode is active.
z
z
In the I/O Group mode, selects group 2 and indicates the selection.
z
z
With the Enter, View, and Esc buttons, selects Serial Port and Audio
and RS-232 Input Configuration mode.
z
z
Selects 19200 baud for the rear panel Remote port in Serial Port and Audio
and RS-232 Input Configuration mode and indicates the selection.
e
View button — The View button has one primary function (
❏
) and five secondary
functions (
•
):
❏
Selects and indicates View mode, which displays the current configuration.
NOTE: View mode also provides a way to mute and unmute the outputs
”).
z
z
In the I/O Group mode, selects group 3 and indicates the selection.
z
z
Decreases the audio level of the selected input.
z
z
Decreases the volume of the selected output.
z
z
With the Enter, Preset, and Esc buttons, selects Serial Port and Audio and
RS-232 Input Configuration mode.
z
z
Selects 38400 baud for the rear panel Remote port in Serial Port and Audio
and RS-232 Input Configuration mode, and indicates the selection.
f
Esc button — The Esc button has two primary functions (
❏
) and five secondary
functions (
•
):
❏
Cancels operations or selections in progress and resets the front panel button
indicators.
NOTE: The Esc button does not reset the current configuration or any presets.
❏
Flashes once to indicate that the escape function has been activated.
z
z
In the I/O Group mode, selects group 4 and indicates the selection.
z
z
Increases the audio level of the selected input.
z
z
Increases the volume of the selected output.
z
z
With the Enter, Preset, and View buttons, selects Serial Port and Audio
and RS-232 Input Configuration mode.
z
z
Selects 115200 baud for the rear panel Remote port in Serial Port and
Audio and RS-232 Input Configuration mode and indicates the
selection.
