Uploading HTML Files
You can create customized HTML pages for the switcher to display. The HTML Files List
window (see figure 44), accessible via the
Tools
menu, provides a way to view the contents
of the file system of the switcher and upload custom HTML pages to the switcher.
7
8
4
Figure 44.
HTML Files List Window
NOTES: • The files listed in figure 44 are shown for example only and may not be
present on your switcher.
• The HTML Files List window is for inserting your own HTML pages. This
is not the window to replace the firmware that controls all switcher
operation (see “
,” to replace the firmware).
• The following characters are invalid or not recommended in file names:
{space} + ~ , @ = ‘ [ ] { } < > ’ “ “ ; : | \ and ?.
Upload HTML pages as follows:
1.
Connect the PC to the matrix switcher via any of the serial ports or the Ethernet port of
the switcher.
2.
Start the Matrix Switchers Control Program and connect to the MTPX Plus matrix
switcher (see “
,” steps 1 through 4, starting on page 90).
3.
Click
Tools
>
HTML File Manager
.
4.
Click the
Pick File(s) to Load to Server
button. An Open File window appears.
5.
Navigate to the folder where you saved the HTML files. Select the files.
NOTES: • To select multiple files, hold the Ctrl key while you select the desired
files.
• If you want one of the HTML files that you created to be the default
start-up page, name the file “index.html.” The MTPX Plus matrix
switcher automatically looks for that file name when you first connect
to it using an Internet browser.
6.
Click the
Open
button. Uploading the files to the MTPX Plus matrix switcher may take a
few minutes.
7.
Click the
Update
button to confirm the upload.
8.
Click the
Close
button to exit the HTML Files List window.
MTPX Plus 6400 Series Matrix Switchers • Matrix Software 103
