Technical Specification
Page B-12
Instruction Manual: evolution 5000 E57xx DSNG and DENG Voyager Encoder
ST.TM.E10076.3
Table B.17: L-Band Monitor Output Specification (E5740-Lband)
Item
Specification
Safety Status:
SELV
Connector Type:
F-type Female
Connector Designation:
L-Band Out Monitor
Output Impedance:
75
W
Output Power:
- 30 dB ± 3 dB relative to main output
Return Loss:
>10 dB, 950 MHz to 1750 MHz
B.3.4
OFDM Modulator Outputs (E5750)
Table B.18: OFDM IF Out 1 Specification (E5750)
Item
Specification
Safety Status:
SELV
Connector Type:
BNC Female
Connector Designation:
IF Out 1 Main
Output Impedance:
75
W
Output Power:
0 dBm
IF Frequency:
70 MHz
Bandwidth:
6 MHz, 7 MHz, or 8 MHz
Modulation:
QPSK, 16QAM or 64QAM
Guard Interval:
1/32, 1/16, 1/8 or 1/4
FEC Rate:
1/2, 2/3, 3/4, 4/5, 5/6 or 7/8
Spectrum sense:
Normal/Inverted
Transmission Modes:
2k mode or 8k mode
Table B.19: OFDM IF Out 2 Specification (E5750)
Item
Specification
Safety Status:
SELV
Connector Type:
BNC Female
Connector Designation:
IF Out 2
Output Impedance:
75
W
Output Power:
- 10 dB relative to IF output 1
B.3.5
ASI Out 1, ASI Out 2, ASI Out 3 Outputs
Table B.20: ASI Out Specification
Item
Specification
Safety status:
SELV
Connector type:
BNC 75
W
Connector designation:
ASI OUT 1, ASI OUT 2, ASI OUT 3
