Operating the Equipment Locally
Page 4-112 Instruction Manual: evolution 5000 E57xx DSNG and DENG Voyager Encoder
ST.TM.E10076.3
EDH Enable Option
To access the EDH Enable option, press the EDH Enable softkey in the
IRD Video Menu
. This allows the pass-through of Error Detection
Hierarchy (EDH) to be either enabled or disabled.
Table 4.149: EDH Enable Options
Selected Option Description
True Pass-through of EDH is enabled.
False Pass-through of EDH is disabled.
Embedded Audio Mode Option
To access the Embedded Audio Mode option, press the Embedded Audio
Mode softkey in the
IRD Video Menu
.
Table 4.150: Embedded Audio Mode Options
Selected Option Description
No Audio No audio is embedded in the SDI output.
Audio 1 Only Audio Channel 1 is embedded in the SDI output.
Audio 2 Only Audio Channel 2 is embedded in the SDI output.
Audio 1 & 2 Audio Channels 1 and 2 are embedded in the SDI output.
Embed Data ID Option
To access the Embed Data ID option, press the Embed Data ID softkey in
the
IRD Video Menu
. This sets the Data ID that is used for the embedded
audio in the SDI output.
Table 4.151: Embed Data ID Options
Selected Option Description
Group 1, Audio 1 to 4 DID 0x2FF
Group 2, Audio 5 to 8 DID 0x1FD
Group 3, Audio 9 to 12 DID 0x1F8
Group 4, Audio 13 to 16 DID 0x2F9
Video PID
The PID of the video service currently being decoded is displayed, but
cannot be changed.
