Remote Gateway 9150 Installation and Administration Guide 21
January 2005 Remote Gateway 9150 description
Voice over IP network call
1 User 1 presses the host call appearance key.
Result: User 1 hears a dial tone. This indicates that the connection to the
RLC over the IP network was successful.
2 User 1 dials a telephone number (such as the extension number of host
station 1).
Result: The dialed digits are sent by the Remote Gateway 9150 unit as
packets across the Ethernet network. The RLC converts the packets to the
format required by the PBX. The PBX then converts the data to voice and
routes the call to host station 1.
PSTN call
1 User 3 presses the host call appearance key.
Result: User 3 hears a dial tone. This indicates that the connection to the
RLC over the PSTN was successful.
2 User 3 dials the telephone number (such as the extension number of host
station 3).
Result: Dialed digits are sent across the PSTN then sent through the host
PBX to host station 3.
