194 Remote Gateway 9150 Installation and Administration Guide
Configuring the Remote Gateway 9150 unit Standard 3.1
DiffServ CodePoint This setting modifies the IP Header and is applicable across the
entire WAN. If enabled, this feature allows you to set the
DiffServ CodePoint value. Refer to the "DiffServ CodePoint:
Value" for a list of values.
!
Click on the Enable option button if you want to allow
prioritization of voice packets sent from this Remote
Gateway 9150 unit over WAN portions of the network.
!
Click on the Disable option button if you do not want to
allow prioritization of voice packets sent from this Remote
Gateway 9150 unit over WAN portions of the network.
The default is Disable.
DiffServ CodePoint:
Value Select the DiffServ CodePoint value from the drop down box.
Valid options and their value (in hexadecimal) are:
!
CS7 (Precedence 7 - Network Control) - 0x38
!
CS6 (Precedence 6 - Inter-network Control) - 0x30
!
EF (Expedited Forwarding) - 0x2E
!
AF41 (Assured Forwarding Class 4, Delay = Normal,
Throughput = High, Reliability = Normal) - 0x22
!
AF31 (Assured Forwarding Class 3, Delay = Normal,
Throughput = High, Reliability = Normal) - 0x1A
!
AF21 (Assured Forwarding Class 2, Delay = Normal,
Throughput = High, Reliability = Normal) - 0x12
!
AF11 (Assured Forwarding Class 1, Delay = Normal,
Throughput = High, Reliability = Normal) - 0x0A
!
DE (Default) - 0x00
The default is EF.
Field Description
