106 Remote Gateway 9150 Installation and Administration Guide
Installing the Remote Gateway 9150 unit Standard 3.1
— The analog device must be located no farther than 307.7 meters
(1000 feet) from the Remote Gateway 9150 unit.
!
Ethernet cable
If you are connecting the Remote Gateway 9150 unit to a hub, you need a
standard CAT5 un-shielded twisted-pair (UTP) straight-through Ethernet
cable. The cable must be no longer than 100 meters (325 feet) in length.
Connector and pin-out reference
The following table identifies where to find the pin-out table for each connector:
More information
The following documents describe how to establish telephone and trunk
connections using the Meridian 1 PBX BIX in-building cross-connect system:
!
Meridian 1 PBX Installation planning (NTP 553-3001-120)
!
Telephone and attendant console installation (NTP 553-3001-215)
!
BIX* In-Building Cross-Connect System Material Installation and
Servicing (Wall-Mounted System) (NTP 631-4511-200)
Connector Connection type For the pin-out table, refer to
TELCO 1 25 TIP and RING pairs page 404.
TELCO 2 25 TIP and RING pairs page 406.
ETHERNET RJ-45 page 408.
ADMIN DB-9 page 409.
Power DIN page 410.
