Remote Gateway 9150 Installation and Administration Guide 309
January 2005 Administration
DSP Statistics field descriptions
The following table describes the statistics on the DSP Statistics screen:
Column Description
Single Digit Device
ID Identifies an internal sequence number for indexing
this DSP device among all others on the RLC.
Module Number Identifies this DSP Application Module’s module
number on the Remote Gateway 9150 unit.
Valid values are 0, 1, 2, and 3.
Device Number Identifies the DSP device that processed the call.
In Service Identifies any voice channels operating on this DSP
application module.
Total MIPS Identifies the total millions of instructions per second
(MIPS) capacity for this DSP device.
Available Mips Identifies the millions of instructions per second
(MIPS) currently available on this DSP device.
Total Channels Identifies the total channel capacity for this DSP
device.
Total Voice Channels Identifies the total voice channel capacity for this DSP
device.
Available Voice
Channels Identifies the number of unused voice channels on this
DSP device.
Total Modem
Channels Identifies the number of channels on this DSP device
that can transmit modem calls.
Available Modem
Channels Identifies the number of unused channels on this DSP
that can transmit modem calls.
Total Flex Channels Identifies the number of channels on this DSP that can
provide multiple functionalities.
Available Flex
Channels Identifies the number of channels on this DSP
currently available to provide multiple functionalities.
