6 Remote Gateway 9150 Installation and Administration Guide
Remote Gateway 9150 description Standard 3.1
!
A DB-9 connector (labeled ADMIN) provides an RS-232 serial port
connection.
You can use this serial port connection to configure a Remote Gateway
9150 unit that is directly connected to a PC.
Refer to Chapter 2, “Planning for Remote Gateway 9150 unit installation,” for a
detailed description of cables and connectors.
Mounting options
The Remote Gateway 9150 unit can be mounted on a desk, in a rack, or on the
wall.
Universal power supply
The Remote Gateway 9150 unit includes an auto-sensing 110/220 V power
supply that is compatible with commercially available UPS systems.Refer to the
diagram on page 7.
Note: If you want to connect the Remote Gateway 9150 unit to a UPS, ensure
that the UPS has a minimum rating of 100 Watts.
