Remote Gateway 9150 Installation and Administration Guide 3
January 2005 Remote Gateway 9150 description
Remote Gateway 9150 hardware description
The Remote Gateway 9150 unit is installed in your office and can be mounted
on a desk, in a rack, or on the wall. This section describes the LED indicator
displays, power supply, cables, and connectors for the unit.
LED indicators on the Remote Gateway 9150 unit
The following diagram shows the LED indicators on the front panel of the
Remote Gateway 9150 unit.
RX
TX
V.35
STATU S
4
3
2
1
L2 L1
L2 L1
L2 L1
L2 L1 MODU LE
COLL RX TX
ETHER
NET
POWE
R
G101402
Power
Note: The V.35 LED indicators are present but are not functional.
Ethernet Modules V.35 Status
Remote Gate
way 9150
