Remote Gateway 9150 Installation and Administration Guide 289
January 2005 Administration
8 On the Upload Configuration dialog box, click on the Save to Flash button.
Result: The FLASH CONFIG dialog box displays, similar to the following:
9 Click on the Yes button.
Result: The following message displays in the status bar at the bottom of
the screen:
Saving to Flash in Progress
When the save is finished, the following message displays in the middle of
the Upload Configuration dialog box:
CONFIGURATION IS UPDATED INTO FLASH...
10 Click on the Close button.
11 Restart the Remote Gateway 9150 unit.
Note: For instructions, refer to “Performing a system restart or shutdown”
on page 169.
IF the upload THEN
is successful, the following message displays:
CONFIG UPLOAD SUCCESSFUL... USE
SAVECFG TO UPDATE FLASH.
Proceed to step 8.
fails, the following message displays in the middle of
the Upload Configuration dialog box:
CONFIG UPLOAD FAILED
For further instructions, refer to Chapter 8,
“Troubleshooting.”
