170 Remote Gateway 9150 Installation and Administration Guide
Using Configuration Manager Standard 3.1
The status continues to show Online. When the system restart is complete,
a dialog box displays informing you that the system restart was successful,
and that you are logged off, similar to the following:
3 Click on the OK button.
Result: Configuration Manager prompts you to log back on using the
previous connection method (Serial or Telnet).
Performing a system shutdown
To perform a system shutdown:
1 From the Menu Bar, choose Connect
→
System Reset
→
Shutdown.
Result: The System Shutdown dialog box displays, similar to the following:
2 Click on the Yes button.
Result: Configuration Manager disconnects your logon session and the
following message displays in the status bar at the bottom of the screen:
Shutting Down the System
The status shows Offline.
3 Turn the power on the Remote Gateway 9100 Series unit off.
Note: You must turn the power off before you can power the unit back up.
ATTENTION
Do not perform this procedure if you do not have physical
access to the unit. To recover from the system shutdown,
you must power the unit off, and then power it back on.
