Mounting the unit on the wall – Nortel Networks 9150 User Manual
Page 131
Remote Gateway 9150 Installation and Administration Guide
101
January 2005
Installing the Remote Gateway 9150 unit
Mounting the unit on the wall
1
Choose the location on the wall where you want to mount the Remote
Gateway 9150 unit.
G101396
OR
Cables must be connected and routed away from the
Remote Gateway 9150 unit at a right angle
To route cables
to the right
To route cables
to the left
37.5 cm (15 in)
15 cm (6 in)
