Remote Gateway 9150 Installation and Administration Guide 189
January 2005 Configuring the Remote Gateway 9150 unit
International Tones field descriptions
Field Description
Tone Type Tones inform users as to call status. Select the tone that
you want to configure.
Valid options are DIAL, RGBK, BUSY, and OVFL.
DIAL – Dial tone signifies that the telephone is ready to
receive dialed digits.
RGBK – Ringback signifies that the dialed line is ringing.
BUSY – Busy signal signifies that the dialed line is not
ready to receive calls.
OVFL – Overflow (congestion) tone signifies that there
are no channels available.
End Repeat
!
Click on the Off option button if you want the tone type
you selected to be a constant tone.
Note: If you chose End Repeat: Off, then the No of
Cycles and Cadence Time fields are dimmed.
!
Click on the Repeat option button if you want the
selected tone type to have on and off phases.
The default is Off.
Tone Code Enter the four-letter LD 56 Tone Code that you want this
Remote Gateway 9150 unit to use for the tone type you
selected.
The default is 4.
