388 Remote Gateway 9150 Installation and Administration Guide
Planning forms Standard 3.1
Remote Gateway 9150
System expansion worksheet
Page 4 of 4
Number of DSP application modules needed:
19 Each DSP application module can support up to eight simultaneous calls over
the IP network.
Add line two to line eight, divide the sum by eight, and round up to the next
whole number.
(Line 2: __________ + Line 10: _____________) / 8 = ______________
___________
20 Record the number of DSP application modules already installed.
Note: The Remote Gateway 9150 unit ships from Nortel with the equivalent of
two DSP application modules built in. Your response here must include those
modules.
___________
21 Calculate how many DSP modules you need to purchase.
Subtract line 20 from line 19.
Note: A maximum of three DSP application modules can be installed in the
Remote Gateway 9150 unit.
___________
