Remote Gateway 9150 Installation and Administration Guide 407
January 2005 Pin-out tables for connections
Module 6
(ISDN BRI—U or ST) 19 MOD 5 Ring 0+ BR-Y 44 Module 5 Ring 0- Y-BR
Module 7
(ISDN BRI—ST only) 20 MOD 6 Tip 0+ SL-Y 45 Module 6 Tip 0- Y-SL
Module 7
(ISDN BRI—U or ST) 21 MOD 6 Ring 0+ BL-V 46 Module 6 Ring 0- V-BL
Module 7
(for future use) 22 MOD 6 Tip 1+ OR-V 47 Module 6 Tip 1- V-OR
Module 7
(for future use) 23 MOD 6 Ring 1+ GR-V 48 Module 6 Ring 1- V-GR
Leave open for UL
spacing requirements 24 Open BR-V 49 Open V-BR
Fault Relay
Contact 1 25 UNUSED 50 UNUSED
Port or module Pin # Signal Color Pin # Signal Color
