Remote Gateway 9150 Installation and Administration Guide 121
January 2005 Installing the Remote Gateway 9150 unit
Enter a node name that
identifies the unit Enter a name that uniquely identifies the
Remote Gateway 9150 unit you are
configuring.
Enter the local IP Address
of the unit Enter the IP address assigned to the
Remote Gateway 9150 unit.
Note: If you do not have a valid IP address,
enter the sample IP address: 10.1.1.2.
Enter the Local IP Mask
of the unit Enter the subnet mask.
Note: If you do not have a valid subnet
mask, enter the sample subnet mask:
255.255.0.0.
Enter the Local IP Gateway
of the unit Enter the IP address of the gateway
between the Remote Gateway 9150 unit
and the network.
Note: If there is no router between the
Remote Gateway 9150 unit and the
network, then the administration PC acts as
the gateway. Enter 10.1.1.10.:
!
as the IP address on the administration
PC
!
as the gateway on the Remote Gateway
9150 unit
Field Description
