122 Remote Gateway 9150 Installation and Administration Guide
Installing the Remote Gateway 9150 unit Standard 3.1
The following is a completed example:
6 Click on the Next button.
Result: The Set the Configuration for the Remote Unit dialog box displays.
A completed example is shown on page 124.
7 Complete the fields on this dialog box as described in the following table:
Field Description
Set the Unit ID of the RLC to
connect to Enter the RLC’s unit ID.
Wish to Enable IP Voice
Connection to Remote
!
Click on the Yes option button to enable
the Voice over IP connection to the
RLC.
Then enter the RLC's 32-bit, decimal
dot notation address (xxx.xxx.xxx.xxx).
This is not the URL's site name that
begins www.
!
Click on the No option button to disable
the Voice over IP connection to the
RLC. Clicking on the No option button
dims the IP Address fields.
The IP information
allows you to
administer the
Remote Gateway
9150 unit from any
location on the
network.
