326 Remote Gateway 9150 Installation and Administration Guide
Administration Standard 3.1
Displaying the ISDN Module Information Statistics screen
Choose Alarms/Stats/Logs
→
ISDN Module Information to display the ISDN
Module Information Statistics screen.
Result: Configuration Manager gathers statistics from the Remote Gateway
9150 unit and displays the ISDN Module Information Statistics screen, similar to
the example on page 325.
ISDN Module Information field descriptions
The following table describes statistics found on the ISDN Module Information
Statistics screen:
IF you want to THEN click
update the statistics with the latest
information, on the Refresh button.
create a text file containing these
statistics, on the Save to File button.
close the ISDN Module Information
Statistics screen, on the Close button.
obtain descriptions of the statistics in
the ISDN Module Information
Statistics screen, on the Help button.
Column Description
Module Number Identifies the module position of the ISDN BRI module.
Valid values are 4, 5, 6, and 7.
Module Type Identifies the type of the ISDN BRI module.
Valid values are BRI-U, BRI-ST, and INVALID.
Link Status Identifies the current status of the ISDN BRI line.
Valid values are UP, DOWN, and INVALID.
Usage Identifies whether the ISDN BRI line is in use or not.
Valid values are IDLE and ACTIVE.
