392 Remote Gateway 9150 Installation and Administration Guide
Sample configuration files Standard 3.1
Voice port configuration on the Meridian 1
PBX
This section shows the configuration settings for the voice port on the
Meridian 1 PBX. Generally, define voice ports according to the needs of your
remote users.
Configuration example
This configuration example uses the settings identified in the network diagram
shown on page 391.
Note: This configuration example is from a Meridian 1 PBX 11.
REQ: prt
TYPE: 2616
MARP NOT ACTIVATED
TN 5 0
DATE
PAGE
DES
DES Bryan Dion
LDN NO
NCOS 0
SGRP 0
RNPG 0
SCI
0
SSU
XLST
RLC slot and port numbers
TN 005 0 00 00
TYPE 2616
CDEN 8D
CUST 0
AOM
0
FDN
TGAR 1
Telephone type
