12.93
6 NC Machine Data (NC MD), NC Setting Data (NC SD)
6.1.4 Breakdown of NC MDs/drive machine data
Number of TO parameters
13
Default value
Lower input limit
Upper input limit
Units
10
10
32
–
Active
see below
Normally, each tool offset has up to ten permanently allocated TO parameters. When required,
the user can upgrade the number of parameters to 32, and must allocate the added param-
eters (10 to 32) using the configuring terminal. The greater the number of TO parameters
allocated to a tool offset, the lower the number of tool offsets available to the user, as the
memory space available for tool offsets is limited.
Parameter
TO
Comments
10
204
409
Initial setting
11
186
372
12
170
341
13
157
315
14
146
292
15
136
273
16
128
256
17
120
240
18
113
227
19
107
215
20
102
204
21
97
195
22
93
186
23
89
178
24
85
170
25
81
163
26
78
157
27
75
151
28
73
146
29
70
141
30
68
136
31
66
132
32
64
128
(16 K tool memory)
Basic version with 8 K tool memory
Note carefully:
Modifications do not take effect until user memory has been formatted.
User memory is formatted in "Overall Reset" mode with either the "Format User Data" or the
"Format TO Data" softkey. For inform. on selecting "Overall Reset" mode, refer to Section
General Reset.
Number of D memories=
Memory configuration [BYTES]
Number of TO parameters *4
For SW 4 and higher see functional description "Flexible Memory Configuration".
©
Siemens AG 1992 All Rights Reserved 6FC5197- AA50
6–13
