SINUMERIK 840C (IA)
4.4.6
Color settings for monochrome display
4.4.6.1
10” monochrome display (up to SW 4.4)
6FC5 103–0AB
V
2–0AA0
Introduction
The BEDCONF, NECOLLI and NEMOCLUT files have to be edited for improving
the quality of the screen display.
In addition, an anti-reflex filter for the screen has to be installed, order number
6FC5148–0AC01–0AA0.
Color setting
BEDCONF
a 1 1 1 11
// BAPLANZ
a 1 1 2 12
// BINPUTMODE
a 1 5 1 MO
// BCOLORMONO_DEF
a 1 5 2 NE
// BPOSNEG_DEF
a 1 7 0 450000
// BSCREENSAVE
Color setting
NECOLLI
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
0
17
0
18
0
19
0
20
0
21
0
22
0
23
0
24
0
25
0
26
0
27
0
28
0
29
0
30
0
31
0
32
0
33
0
34
0
35
0
36
0
37
0
38
0
39
0
40
0
41
0
42
0
43
0
44
0
45
0
46
0
47
0
48
0
49
0
50
0
51
0
52
0
53
0
54
0
55
0
56
0
57
0
58
0
59
0
60
0
61
0
62
0
63
0
64
0
65
14
66
7
67
0
68
0
69
14
70
0
71
7
72
5
73
4
74
0
75
2
76
0
77
4
78
15
79
7
80
11
81
2
82
0
83
4
84
2
85
15
86
15
87
14
88
0
89
12
90
8
91
7
92
1
93
2
94
4
95
3
96
6
97
5
98
12
99
8
100
4
101
7
102
0
103
6
104
3
105
0
106
4
107
0
108
0
109
0
110
0
111
0
112
1
113
8
114
12
115
11
116
11
117
11
118
11
119
0
120
0
121
13
122
0
123
0
124
0
125
0
126
0
127
0
Color setting
NEMOCLUT
0
0
0
794
794
794
1000
1000
1000
1000
1000
1000
1000
1000
1000
604
604
604
698
698
698
1000
1000
1000
524
524
524
413
413
413
0
0
0
0
0
0
159
159
159
508
508
508
950
950
950
80
80
80
4.4.6.2
9.5” monochrome display (as from SW 4.5)
In the case of a positive display the basic setting of the ASCII editor must also be
changed.
In file BEDCONF
Entry
i 1 2 2207 0//BAEFGCOLOR_DFLT
replace with
i 1 2 2207 5//BAEFGCOLOR_DFLT
