MOVMSKPS—Extract Packed Single-Precision Floating-Point Sign Mask

Description

Extracts the sign bits from the packed single-precision floating-point values in the
source operand (second operand), formats them into a 4-bit mask, and stores the
mask in the destination operand (first operand). The source operand is an XMM
register, and the destination operand is a general-purpose register. The mask is
stored in the 4 low-order bits of the destination operand.
In 64-bit mode, the instruction can access additional registers (XMM8-XMM15,
R8-R15) when used with a REX.R prefix. Use of the REX.W prefix promotes the
instruction to 64-bit operands. See the summary chart at the beginning of this
section for encoding data and limits.

Operation

DEST[0] ← SRC[31];

DEST[1] ← SRC[63];

DEST[2] ← SRC[95];

DEST[3] ← SRC[127];

IF DEST = r32

THEN DEST[31:4] ← ZeroExtend;

ELSE DEST[63:4] ← ZeroExtend;

FI;

Intel C/C++ Compiler Intrinsic Equivalent

int _mm_movemask_ps(__m128 a)

SIMD Floating-Point Exceptions

None.

Protected Mode Exceptions

#NM

If CR0.TS[bit 3] = 1.

Opcode

Instruction

64-Bit

Mode

Compat/

Leg Mode

Description

0F 50 /r

MOVMSKPS r32,

xmm

Valid

Extract 4-bit sign mask from xmm

and store in r32.

REX.W + 0F 50 /r

MOVMSKPS r64,

xmm

Valid

N.E.

Extract 4-bit sign mask from xmm

and store in r64. Zero extend

32-bit results to 64-bits.
