Vol. 2A 3-535
INSTRUCTION SET REFERENCE, A-M
LEA—Load Effective Address
LEA—Load Effective Address
Description
Computes the effective address of the second operand (the source operand) and
stores it in the first operand (destination operand). The source operand is a memory
address (offset part) specified with one of the processors addressing modes; the
destination operand is a general-purpose register. The address-size and operand-size
attributes affect the action performed by this instruction, as shown in the following
table. The operand-size attribute of the instruction is determined by the chosen
register; the address-size attribute is determined by the attribute of the code
segment.
Different assemblers may use different algorithms based on the size attribute and
symbolic reference of the source operand.
In 64-bit mode, the instruction’s destination operand is governed by operand size
attribute, the default operand size is 32 bits. Address calculation is governed by
address size attribute, the default address size is 64-bits. In 64-bit mode, address
size of 16 bits is not encodable. See Table 3-59.
Opcode Instruction 64-Bit
Mode
Compat/
Leg Mode
Description
8D /r LEA r16,m Valid Valid Store effective address for m in register
r16.
8D /r LEA r32,m Valid Valid Store effective address for m in register
r32.
REX.W + 8D /r LEA r64,m Valid N.E. Store effective address for m in register
r64.
Table 3-58. Non-64-bit Mode LEA Operation with Address and Operand Size
Attributes
Operand Size Address Size Action Performed
16 16 16-bit effective address is calculated and stored in
requested 16-bit register destination.
16 32 32-bit effective address is calculated. The lower 16 bits of
the address are stored in the requested 16-bit register
destination.
32 16 16-bit effective address is calculated. The 16-bit address is
zero-extended and stored in the requested 32-bit register
destination.
32 32 32-bit effective address is calculated and stored in the
requested 32-bit register destination.
