3-642 Vol. 2A MOVLPS—Move Low Packed Single-Precision Floating-Point Values
INSTRUCTION SET REFERENCE, A-M
MOVLPS—Move Low Packed Single-Precision Floating-Point Values
Description
Moves two packed single-precision floating-point values from the source operand
(second operand) and the destination operand (first operand). The source and desti-
nation operands can be an XMM register or a 64-bit memory location. This instruction
allows two single-precision floating-point values to be moved to and from the low
quadword of an XMM register and memory. It cannot be used for register to register
or memory to memory moves. When the destination operand is an XMM register, the
high quadword of the register remains unchanged.
In 64-bit mode, use of the REX.R prefix permits this instruction to access additional
registers (XMM8-XMM15).
Operation
MOVLPD instruction for memory to XMM move:
DEST[63:0] ← SRC;
(* DEST[127:64] unchanged *)
MOVLPD instruction for XMM to memory move:
DEST ← SRC[63:0];
Intel C/C++ Compiler Intrinsic Equivalent
MOVLPS __m128 _mm_loadl_pi ( __m128 a, __m64 *p)
MOVLPS void _mm_storel_pi (__m64 *p, __m128 a)
SIMD Floating-Point Exceptions
None.
Protected Mode Exceptions
#GP(0) For an illegal memory operand effective address in the CS, DS,
ES, FS or GS segments.
Opcode Instruction 64-Bit
Mode
Compat/
Leg Mode
Description
0F 12 /r MOVLPS xmm,
m64
Valid Valid Move two packed single-precision
floating-point values from m64 to low
quadword of xmm.
0F 13 /r MOVLPS m64,
xmm
Valid Valid Move two packed single-precision
floating-point values from low
quadword of xmm to m64.
