Page 27: Symbols on the product

background image

3.3.4.3

Status Symbols

Depending on the status of the device communication, the device symbols are displayed in the tree or device view with
various status symbols.

Symbol

Explanation

The inverter is ready for operation.

There is an error in the inverter.

An error has occurred in the communication with the inverter.

3.4

Symbols on the Product

The following gives an explanation of all the symbols found on the inverter and on the type label.

Symbol

Designation

Explanation

CE marking

The product complies with the requirements of the applicable EU di-
rectives.

Protection class I

All electrical equipment is connected to the grounding conductor sys-
tem of the product.

Degree of protection IP54

The product is protected against interior dust deposits and splashing
water from all angles.

Beware of a danger zone

This warning symbol indicates a danger zone. Be particularly vigilant
and cautious when working on the product.

Beware of dangerous volt-
age

The product operates at high voltages. All work on the product must
be carried out by qualified persons only.

Beware of hot surface

The product can get hot during operation. Avoid contact during oper-
ation. Allow the product to cool down sufficiently before carrying out
any work. Wear personal protective equipment such as safety
gloves.

Use hearing protection.

The product generates loud noises. When working on the product,
wear hearing protection.

Observe the documenta-
tion.

Observe all documentation supplied with the product.

3 Product Overview

SMA Solar Technology AG

User Manual

27

SCCPXT-BA-E4-en-54
