Name Description Value/range Explanation Default
value
QoDQ-
VArMod** Reactive power setpoint
in the operating mode
"Q at Night" Off Sets reactive power to 0 kVAr
and displacement power factor
cos φ to 1 Off
VArCtlCom Specifies reactive power via ex-
ternal control unit, such as the
Power Reducer Box
VArCnst Specifies reactive power in kVAr
via the parameter QoDQ-VAr
VArCnstNom Specifies reactive power in % via
the parameter QoDQ-VArNom
VArCnstNomAnIn The reactive power setpoint is im-
ported via an analog input.
VArCtlVol Specifies reactive power as a
function of the grid voltage
VArCtlVolHystDb Specifies reactive power as a
function of the grid voltage (Q =
f(V) characteristic curve)
Q-VAr Reactive power in kVAr −245 kVAr to
+245 kVAr Sunny Central 500CP XT 0 kVAr
−310 kVAr to
+310 kVAr Sunny Central 630CP XT
−346 kVAr to
+346 kVAr Sunny Central 720CP XT
−365 kVAr to
+365 kVAr Sunny Central 760CP XT
−385 kVAr to
+385 kVAr Sunny Central 800CP XT
−409 kVAr to
+409 kVAr Sunny Central 850CP XT
−433 kVAr to
+433 kVAr Sunny Central 900CP XT
